JBL Bar 800 MK2 Dolby Atmos Soundbar Surround Sound 7.1CH


The JBL BAR 800MK2 delivers real, immersive surround sound in seconds, including 3D Dolby Atmos® and punchy bass from a 10″ subwoofer. Take one of the wireless speakers along if you need to step away, and you’ll never miss a thing.

280,000

Compare

REAL SURROUND SOUND WITH DETACHABLE WIRELESS SPEAKERS

It’s never been easier to jump into true surround sound. No extra wires. No power connections. Just lift the detachable surround speakers off the soundbar—you can do it with just one hand—and place them behind you in the room for true surround sound. It’s that simple. Whether you’re binge-watching your new favorite show or hosting a movie night, the speakers’ long-lasting batteries mean you’ll enjoy immersive, cinematic surround sound for hours. When you’re done, simply place them back on the soundbar to charge overnight.

JBL Bar 800MK2 780W max output power and a 10" wireless subwoofer - Image

780W MAX OUTPUT POWER AND A 10″ WIRELESS SUBWOOFER

Feel like you’re part of the action as a climactic battle scene unfolds. Surrender to the beat of your favorite song. Your movies, music, and games become an even more vivid and immersive sound experience with 780 watts of total system power, including big, thundering bass from the 10″” wireless subwoofer.

JBL Bar 800MK2 Dolby Atmos® - Image

DOLBY ATMOS®

Hear a plane soar overhead. Feel a crowd swarming past you. Or get carried away by the energy of your go-to dance playlist. Hear extraordinary cinematic sound from all directions with the 3D audio experience of Dolby Atmos®.

brands

JBL

Audio type

Sound Bars

General Specifications

Sound system
7.1 channel
Power supply
100 – 240V AC, ~ 50/60Hz
Total speaker power output* (Max. @THD 1%)
780W
Soundbar output power** (Max. @THD 1%)
400W
Surround speaker output power*** (Max. @THD 1%)
2x 40W
Subwoofer output power**** (Max. @THD 1%)
300W
* RMS @THD 1%

* RMS @THD 1%200W *** RMS @THD 1%
390W ** RMS @THD 1%
Soundbar transducer
6x (44×80)mm racetrack drivers, 2x 1″ (25mm) tweeters
Surround speaker transducer
2x (44×90)mm racetrack drivers
Subwoofer transducer
10” (260mm)
Networked standby power
< 2.0 W
Operating temperature
0°C – 45 °C
Lithium battery
3.635V, 3283mAh
Detachable surround speaker playtime
up to 10 hours (may vary according to content type and volume level)

Audio Specifications

Frequency response
35Hz – 20kHz (-6dB)
Audio inputs
Optical, Bluetooth, USB (USB playback
is available in US version. For other versions, USB is for Service only.)

Dimensions

Total soundbar dimensions (W x H x D)
1163 x 52 x 128mm / 45.8″ x 2.0″ x 5.0″
Soundbar dimensions (W x H x D)
854 x 52 x 128mm / 35.6″ x 2.0″ x 5.0″
Detachable surround speaker dimensions (each) (W x H x D)
169 x 52 x 128mm / 6.7″ x 2.0″ x 5.0″
Subwoofer dimensions (W x H x D):
325 x 400 x 325 mm / 12.8″ x 15.7″ x 12.8″
Soundbar weight
5kg / 11lbs
Detachable surround speaker weight (each)
0.7 kg / 1.6 lbs
Subwoofer weight
8.1kg / 17.8 lbs
Packaging dimensions (W x H x D)
980 x 398 x 495 mm / 38.58″ x 15.67″ x 19.49″
Packaging Weight
20.8kg / 45.9lbs (EMEA/UK/AU/NZ); 18.08kg / 41.4lbs (Others)

Control and Connection Specifications

USB port
Type A
USB rating
5V DC, 0.5A
Supporting file formats
mp3
MP3 codec
MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3
MP3 sampling rate
16 – 48 kHz
MP3 bitrate
80 – 320 kbps
Bluetooth version
v5.3
Bluetooth profile
A2DP v1.3, AVRCP v1.5
Bluetooth transmitter frequency range
2400 MHz – 2483.5 MHz
Bluetooth transmitter power
<15 dBm (EIRP)
Wi-Fi network
IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range
2412 – 2472 MHz (2.4 GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power
< 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range
5.15 – 5.35GHz, 5.470 – 5.725GHz, 5.725 – 5.825GHz
5G Wi-Fi transmitter power
5.15 – 5.25GHz <23dBm,
5.25 – 5.35GHz & 5.470 – 5.725GHz <20dBm, 5.725 – 5.825GHz <14dBm (EIRP)
2.4G wireless transmitter frequency range
2406 – 2474MHz
2.4G wireless transmitter power
<10dBm (EIRP)
Note
Band 5.6 – 5.64 GHz will be disabled when shipped to Australia / New Zealand.

Video Specifications

HDMI video input
1
HDMI video output (with Enhanced Audio Return Channel, eARC)
1
HDMI HDCP version
2.3
HDR pass through
HDR10+, Dolby Vision
