JBL Bar 1300 MK2 Dolby Atmos soundbar 11.1.4ch

Name: JBL Bar 1300 MK2 Dolby Atmos soundbar 11.1.4ch
SKU: JBLBAR1300MK2
Availability: InStock

Compare

11.1.4 channel soundbar system with detachable surround speakers, MultiBeam 3.0™, Dolby Atmos® and DTS:X®

₨450,000

Compare

Description
Specification

Features

Real atmospheric surround sound with detachable wireless speakers

Experience the pinnacle of 3D surround sound with breathtaking height channels. Six up-firing speakers in the soundbar and the wireless rear speakers deliver true Dolby Atmos® sound. No extra wires. No power connections. Just lift the detachable surround speakers off the soundbar—you can do it with just one hand—and place them behind where you’re sitting to create a true surround-sound experience. It’s that simple. Whether you’re binge-watching your new favorite show or hosting a movie night, the speakers’ long-lasting batteries mean you’ll enjoy immersive, cinematic surround sound for hours. And when you’re done, just place the speakers back on the bar to recharge overnight.

2470W max output power and an 8″ dual-driver wireless subwoofer

Get ready. With a staggering 2470 total watts of max output power, your movies, music, and games will sound like nothing you’ve ever heard outside of a top-quality movie theater. Feel a spaceship zoom into hyperdrive, or the roar of a high-speed car chase. The powerful 8″ dual-driver subwoofer delivers a remarkable 1200 watts of max output power from a small, elegantly rounded silhouette that blends into your room’s decor.

True Dolby Atmos® and DTS:X

Plunge into theater-quality 3D spatial sound with true Dolby Atmos® and DTS:X. Shiver as spaceships fill the sky overhead. Feel explosions that rumble through your body. Experience music like you’re right there in the recording studio.

SKU: JBLBAR1300MK2 Categories: Audio Devices, JBL, Soundbars, Tv & Audio Tags: JBL BAR 1300MK2 11.1.4, Lahore Pakistan, Online electronics store

brands	JBL
Audio type	Sound Bars

General Specifications

ModelBAR 1300MK2 (soundbar unit) BAR 1300MK2 SURROUND (detachable speaker) BAR 1300MK2 SUB (subwoofer unit)

Sound system 11.1.4 channel

Power supply100 – 240V AC, ~ 50/60Hz

Total speaker power output* (Max. @THD 1%)2470W

Soundbar output power** (Max. @THD 1%)950W

Surround speaker output power*** (Max. @THD 1%)2x 160W

Subwoofer output power**** (Max. @THD 1%)1200W

Soundbar transducer8x (50x75mm) racetrack drivers, 7x 1″ (25mm) tweeters, 4x 3″ (75mm) up-firing full-range drivers

Surround speaker transducer2x (50x90mm) racetrack drivers, 1x 2″ (50mm) full-range drivers, 1x 3″ (75mm) up-firing full-range drivers

Subwoofer transducer2x 8″ (200mm)

Networked standby power< 2 W

Operating temperature0°C – 45°C

Lithium battery7.2V, 4722mAh

Detachable surround speaker playtimeup to 10 hours (may vary according to content type and volume level)

Audio Specifications

Frequency response33Hz – 20kHz (-6dB)

Audio inputsOptical, Bluetooth, USB (USB playback is available in US version. For other versions, USB is for Service only.)

Dimensions

Total soundbar dimensions (W x H x D)1404 x 58 x 136mm / 55.3″ x 2.3″ x 5.4″

Soundbar dimensions (W x H x D)1030 x 58 x 136mm / 40.6″ x 2.3″ x 5.4″

Detachable surround speaker dimensions (each) (W x H x D)202 x 58 x 136mm / 8″ x 2.3″ x 5.4″

Subwoofer dimensions (W x H x D)315 x 277 x 275mm / 12.4” x 10.9” x 10.8”

Soundbar weight5.93kg / 13lbs

Detachable surround speaker weight (each)1.3 kg / 2.8lbs

Subwoofer weight12kg / 26.5lbs

Packaging dimensions (W x H x D)1124 x 381 x 452 mm / 44.3″ x 15″ x 17.8″

Packaging Weight28.6kg / 63.1lbs (EMEA/UK) 24.3kg / 53.6lbs (JP/IN/CN) 28.8kg / 63.5lbs (AU/NZ) 24.5kg / 54.0lbs (APAC Others)

* RMS @THD 1%1235W ** RMS @THD 1%

Control and Connection Specifications

USB portType A

USB rating5V DC, 0.5A

Supporting file formatsmp3

MP3 codecMPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3

MP3 sampling rate16 – 48 kHz

MP3 bitrate80 – 320 kbps

Bluetooth versionMain Bar – v5.3, Detachable surround speaker – v5.4

Main bar Bluetooth profileA2DP v1.3, AVRCP v1.5 Detachable surround speaker Bluetooth profile

Bluetooth transmitter frequency range2400 MHz – 2483.5 MHz

Bluetooth transmitter power<15 dBm (EIRP)

Wi-Fi networkIEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)

2.4G Wi-Fi transmitter frequency range2412 – 2472 MHz (2.4 GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)

2.4G Wi-Fi transmitter power< 20 dBm (EIRP)

5G Wi-Fi transmitter frequency range5.15 – 5.35GHz, 5.470 – 5.725GHz, 5.725 – 5.825GHz

5G Wi-Fi transmitter power5.15 – 5.25GHz <23dBm, 5.25 – 5.35GHz & 5.470 – 5.725GHz <20dBm, 5.725 – 5.825GHz <14dBm (EIRP)

5G wireless transmitter power5.15 – 5.25GHz <23dBm (EIRP) , 5.25 – 5.35GHz & 5.470 – 5.725GHz <20dBm (EIRP) , 5.725 – 5.825GHz <14dBm (EIRP)

NoteBand 5.6 – 5.64 GHz will be disabled when shipped to Australia / New Zealand.
